The general settings apply to all charts. Most can be set for the whole store or per website, and the texts also per store view.
Stores › Configuration › Magelan › Size guide
You also reach the settings from the menu Content › Size guide › Settings or with the Settings button above the chart list.
1. General
- Enable size guide: the main switch.
- Wizard (find my size): Yes means three steps (group, measurement, result) with a "Select size" button. No means the link opens only the size chart, with no steps and no button.
- Default unit: centimetres or inches. The customer can always switch.
- Rule between sizes: Larger size (default) suggests the smallest size that is equal to or larger than the measurement. Nearest size suggests the closer one. An exact match always gives that size.
- Show full table by default: the chart is already open below the result.
- Remember last measurement: No by default. With Yes the customer's browser stores the measurement (in localStorage) and fills it in on the next product. The measurement never goes to the server.
2. Display
- Link position: Next to the size selector (if the product has no size selector, the link is shown below the price), Below the Add to Cart button or As a tab in the product details (the tab shows the chart and a button for the wizard).
- Link text: empty means "Check your size" with the wizard or "Size chart" without it, translated.
- Show link icon: a tape measure icon before the text.
- Accent colour: empty means the theme's colour. A darker shade for text and a light one for backgrounds are derived from it; the tape on the pictures is drawn in this colour too.
- Size attributes: attribute codes of the size selector, comma separated (default
size). The size is selected in the first one the product uses. - Brand attribute: the attribute used for brand assignments (default
manufacturer).
3. Texts
Modal title, Out of range message, Size not available message and Select button text. Empty fields use the built-in, translated text; {size} is replaced by the recommended size. The texts of a single chart (question, how to measure, column names, note) are set in the chart itself.
4. What customers see on a phone
On Luma the window slides in from the side and covers the screen; on Hyvä it opens from the bottom. On a narrow screen the chart scrolls sideways and the first column stays in place.
After changing the settings, flush the cache (System › Cache Management) so the change shows on product pages. Own pictures are described in Size guide: own images.
